SplitRec：在隐语中使用拆分 BST 算法（Torch 后端）#
阿里搜索推荐团队在 2019 年 arXiv 上发布文章《Behavior Sequence Transformer for E-commerce Recommendation in Alibaba》，提出 BST 模型。BST 利用 Transformer 结构捕捉用户行为序列信息，解决 WDL、DIN 等模型忽略序列信息的问题，因而受到关注。本文将介绍如何在隐语中使用拆分 BST 算法。
BST 模型#
BST 模型在 DNN 模型基础上，使用 Transformer Layer 捕捉用户行为序列中的信息，整体结构如下
其中 Transformer Layer 使用一层 multi-head self-attention 结构，如图右侧所示。
Transformer layer 的输入是序列特征的 Embedding 和位置 Embedding 的加和。
隐语中的拆分 BST 模型#
隐语考虑两方拆分学习场景，两方各持有一些特征，包括序列特征和其他特，一方持有 label 。双方特征经过 base 模型处理后，将 base 模型的输出输入到 fuse 模型进行学习，根据对序列特征的处理不同分为拆分 BST 模型和拆分 BSTPlus 模型。
拆分 BST 模型#
其中序列特征通过 Transformer Layer 处理，其他特征通过普通的 Embedding 处理，序列特征和其他特征是可选的，模型结构如图所示。
拆分 BSTPlus 模型#
上述 BST 模型虽然能够有效捕捉序列信息，但对于同一用户不同商品的预估来说，序列信息都是相同的，并不能区分同一用户行为序列与不同商品的关联性，因此 BSTPlus 模型在 BST 基础上叠加 DIN 中的 attention 思想，对 target item 和 Transformer layer 的输出进行 attention pooling，通过计算 target item 对序列中 item 的注意力来挖掘用户行为序列与 target item 之间的关联信息，结构如下图。由于 target item 存在于 label 方，暂不支持无 label 方有序列特征。
隐语封装#
我们在隐语中提供了对于各种应用的封装。 关于 BST 的封装在 secretflow/ml/nn/applications/sl_bst_torch.py，提供了 BSTBase BSTPlusBase 和 BSTFuse 几个类。 下面我们通过一个例子来看一下如何使用隐语封装的 BST 来进行训练。
环境设置#
[1]:
import secretflow as sf
# Check the version of your SecretFlow
print('The version of SecretFlow: {}'.format(sf.__version__))
# In case you have a running secretflow runtime already.
sf.shutdown()
sf.init(['alice', 'bob'], address="local", log_to_driver=False)
alice, bob = sf.PYU('alice'), sf.PYU('bob')
The version of SecretFlow: 1.1.0.dev20230926
2023-09-26 19:48:53,161 INFO worker.py:1538 -- Started a local Ray instance.
数据集介绍#
这里将使用最经典的 MovieLens 数据集进行演示。 MovieLens 是一个开放式的推荐系统数据集，包含了电影评分和电影元数据信息。
下载并处理数据#
我们通过聚合同一用户按时间顺序评分过的电影生成用户行为序列，并对数据进行切分：
- alice: user_id, target_movie_id, sequence_movie_ids, label
- bob: gender, age_group, occupation
[2]:
import os
from pathlib import Path
import shutil
data_dir = './test_bst_data'
dataset_download_dir = data_dir + '/data_download'
gen_data_path = data_dir + '/data_sl_bst'
fea_emb_input_size = {}
def generate_data():
import numpy as np
import pandas as pd
from secretflow.utils.simulation.datasets import _DATASETS, get_dataset, unzip
global dataset_download_dir
# download dataset
if not Path(dataset_download_dir).is_dir():
filepath = get_dataset(_DATASETS['ml-1m'])
unzip(filepath, dataset_download_dir)
dataset_dir = dataset_download_dir + '/ml-1m'
# read data
users = pd.read_csv(
dataset_dir + "/users.dat",
sep="::",
names=["user_id", "gender", "age_group", "occupation", "zip_code"],
engine='python',
)
movies = pd.read_csv(
dataset_dir + "/movies.dat",
sep="::",
names=["movie_id", "title", "genres"],
engine='python',
encoding="ISO-8859-1",
)
ratings = pd.read_csv(
dataset_dir + "/ratings.dat",
sep="::",
names=["user_id", "movie_id", "rating", "unix_timestamp"],
engine='python',
)
users["user_id"] = users["user_id"].apply(lambda x: f"{x}")
users["age_group"] = users["age_group"].apply(lambda x: f"{x}")
users["occupation"] = users["occupation"].apply(lambda x: f"{x}")
movies["movie_id"] = movies["movie_id"].apply(lambda x: f"{x}")
movies["genres"] = movies["genres"].apply(lambda x: ','.join(x.split('|')))
ratings["movie_id"] = ratings["movie_id"].apply(lambda x: f"{x}")
ratings["user_id"] = ratings["user_id"].apply(lambda x: f"{x}")
ratings["rating"] = ratings["rating"].apply(lambda x: float(x))
# encode movie_id
from sklearn.preprocessing import LabelEncoder
le = LabelEncoder()
le.fit(movies['movie_id'].unique())
movies['movie_id'] = (
le.transform(movies['movie_id']) + 1
) # reserve index 0 for padding
movies['movie_id'] = movies['movie_id'].astype('string')
ratings["movie_id"] = le.transform(ratings["movie_id"]) + 1
ratings['movie_id'] = ratings['movie_id'].astype('string')
fea_emb_input_size['target_id'] = len(movies['movie_id'].unique()) + 1
# generate users' movie sequence
ratings_group = ratings.sort_values(by=["unix_timestamp"]).groupby("user_id")
ratings_data = pd.DataFrame(
data={
"user_id": list(ratings_group.groups.keys()),
"movie_ids": list(ratings_group.movie_id.apply(list)),
"ratings": list(ratings_group.rating.apply(list)),
"timestamps": list(ratings_group.unix_timestamp.apply(list)),
}
)
sequence_length = 5
step_size = 4
def create_sequences(values, window_size, step_size):
sequences = []
start_index = 0
while True:
end_index = start_index + window_size
seq = values[start_index:end_index]
if len(seq) < window_size:
if len(seq) > 1:
seq.extend(['0'] * (window_size - len(seq)))
sequences.append(seq)
break
sequences.append(seq)
start_index += step_size
return sequences
ratings_data.movie_ids = ratings_data.movie_ids.apply(
lambda ids: create_sequences(ids, sequence_length, step_size)
)
ratings_data.ratings = ratings_data.ratings.apply(
lambda ids: create_sequences(ids, sequence_length, step_size)
)
del ratings_data["timestamps"]
ratings_data_movies = ratings_data[["user_id", "movie_ids"]].explode(
"movie_ids", ignore_index=True
)
ratings_data_rating = ratings_data[["ratings"]].explode(
"ratings", ignore_index=True
)
ratings_data_transformed = pd.concat(
[ratings_data_movies, ratings_data_rating], axis=1
)
ratings_data_transformed = ratings_data_transformed.join(
users.set_index("user_id"), on="user_id"
)
# last movie in sequence is target movie
ratings_data_transformed['movie_id'] = ratings_data_transformed.movie_ids.apply(
lambda x: x[-1] if '0' not in x else x[x.index('0') - 1]
)
# remove last movie from seqnuence to generate movie sequence
ratings_data_transformed.movie_ids = ratings_data_transformed.movie_ids.apply(
lambda x: ",".join(x[:-1])
if '0' not in x
else ",".join(x[: x.index('0') - 1] + x[x.index('0') :])
)
# target movie's rating
ratings_data_transformed['label'] = ratings_data_transformed.ratings.apply(
lambda x: x[-1] if '0' not in x else x[x.index('0') - 1]
)
ratings_data_transformed.ratings = ratings_data_transformed.ratings.apply(
lambda x: ",".join([str(v) for v in x[:-1]])
)
ratings_data_transformed = ratings_data_transformed.join(
movies.set_index("movie_id"), on="movie_id"
)
del (
ratings_data_transformed["zip_code"],
ratings_data_transformed["title"],
ratings_data_transformed["genres"],
ratings_data_transformed["ratings"],
)
ratings_data_transformed.rename(
columns={"movie_ids": "sequence_movie_ids", "movie_id": "target_movie_id"},
inplace=True,
)
# encoder: str to id
le = LabelEncoder()
ratings_data_transformed[
['user_id', 'gender', 'age_group', 'occupation']
] = ratings_data_transformed[
['user_id', 'gender', 'age_group', 'occupation']
].apply(
le.fit_transform
)
fea_emb_input_size['user_id'] = len(ratings_data_transformed['user_id'].unique())
fea_emb_input_size['gender'] = len(ratings_data_transformed['gender'].unique())
fea_emb_input_size['age_group'] = len(
ratings_data_transformed['age_group'].unique()
)
fea_emb_input_size['occupation'] = len(
ratings_data_transformed['occupation'].unique()
)
# split train/test
random_selection = np.random.rand(len(ratings_data_transformed.index)) <= 0.85
train_data = ratings_data_transformed[random_selection]
test_data = ratings_data_transformed[~random_selection]
if os.path.exists(gen_data_path):
shutil.rmtree(gen_data_path)
os.mkdir(gen_data_path)
train_data.to_csv(
gen_data_path + "/train_data.csv", index=False, sep="|", encoding='utf-8'
)
test_data.to_csv(
gen_data_path + "/test_data.csv", index=False, sep="|", encoding='utf-8'
)
train_data_alice = train_data[
["user_id", "sequence_movie_ids", "target_movie_id", "label"]
]
train_data_bob = train_data[
[
"gender",
"age_group",
"occupation",
]
]
test_data_alice = test_data[
["user_id", "sequence_movie_ids", "target_movie_id", "label"]
]
test_data_bob = test_data[
[
"gender",
"age_group",
"occupation",
]
]
train_data_alice.to_csv(
gen_data_path + "/train_data_alice.csv", index=False, sep="|", encoding='utf-8'
)
train_data_bob.to_csv(
gen_data_path + "/train_data_bob.csv", index=False, sep="|", encoding='utf-8'
)
test_data_alice.to_csv(
gen_data_path + "/test_data_alice.csv", index=False, sep="|", encoding='utf-8'
)
test_data_bob.to_csv(
gen_data_path + "/test_data_bob.csv", index=False, sep="|", encoding='utf-8'
)
generate_data()
[3]:
! head ./test_bst_data/data_sl_bst/train_data_alice.csv
user_id|sequence_movie_ids|target_movie_id|label
0|2374,768,296,28|1435|3.0
0|1435,876,2620,228|1950|5.0
0|1950,1723,3580,213|3796|4.0
0|3796,3460,1825,1014|1089|5.0
0|1015,34,1078,539|107|4.0
0|107,3791,314,1941|269|4.0
0|269,1903,3517,2076|3375|4.0
0|3375,2295,1935,35|1414|3.0
0|1414,216,3444,1498|582|4.0
[4]:
! head ./test_bst_data/data_sl_bst/train_data_bob.csv
gender|age_group|occupation
0|0|2
0|0|2
0|0|2
0|0|2
0|0|2
0|0|2
0|0|2
0|0|2
0|0|2
到这里，我们以及产出训练测试用的数据文件。
构造 dataset_builder 处理数据#
这里对特征进行 ID 化处理，rating > 3 作为正样本，否则作为负样本
[5]:
import torch
from torch.utils.data import DataLoader, Dataset
# transform DataFrame to Dataset
class AliceDataset(Dataset):
def __init__(self, df, label_df, vocab_dir):
self.df = df
self.label_df = label_df
def __getitem__(self, index):
user_id = torch.tensor([int(self.df["user_id"].iloc[index])])
seq_ids = torch.tensor(
[int(sid) for sid in self.df["sequence_movie_ids"].iloc[index].split(',')]
)
target_id = torch.tensor([int(self.df["target_movie_id"].iloc[index])])
label = 1 if self.label_df["label"].iloc[index] > 3 else 0
return (user_id, target_id, seq_ids), label
def __len__(self):
return len(self.label_df)
class BobDataset(Dataset):
def __init__(self, df, vocab_dir):
self.df = df
def __getitem__(self, index):
gender = torch.tensor([self.df["gender"].iloc[index]])
age = torch.tensor([self.df["age_group"].iloc[index]])
occupation = torch.tensor([self.df["occupation"].iloc[index]])
return (
gender,
age,
occupation,
)
def __len__(self):
return len(self.df)
def create_dataset_builder_alice(batch_size=32):
def dataset_builder(x):
data_set = AliceDataset(x[0], x[1], gen_data_path)
dataloader = DataLoader(
dataset=data_set,
batch_size=batch_size,
)
return dataloader
return dataset_builder
def create_dataset_builder_bob(batch_size=32):
def dataset_builder(x):
data_set = BobDataset(x[0], gen_data_path)
dataloader = DataLoader(
dataset=data_set,
batch_size=batch_size,
)
return dataloader
return dataset_builder
batch_size = 128
dataset_buidler_dict = {
alice: create_dataset_builder_alice(batch_size=batch_size),
bob: create_dataset_builder_bob(
batch_size=batch_size,
),
}
定义模型结构#
通过 mode 指定 base 模型结构 - mode=‘ori’: BSTBase - mode=‘plus’: BSTPlusBase
[6]:
from secretflow.ml.nn.applications.sl_bst_torch import BSTBase, BSTBasePlus, BSTfuse
def create_base_model_alice(mode="ori"):
def create_model():
fea_emb_size = {
"user_id": [fea_emb_input_size["user_id"], 8],
"target_id": [fea_emb_input_size["target_id"], 9],
}
fea_list = ["user_id", "target_id", "sequence_movie_ids"]
if mode == "ori":
model = BSTBase(
fea_list=fea_list,
fea_emb_dim=fea_emb_size,
sequence_fea=["sequence_movie_ids"],
target_item_fea="target_id",
seq_len={"sequence_movie_ids": 4},
padding_idx=0,
)
else:
model = BSTBasePlus(
fea_list=fea_list,
fea_emb_dim=fea_emb_size,
sequence_fea=["sequence_movie_ids"],
target_item_fea="target_id",
seq_len={"sequence_movie_ids": 4},
padding_idx=0,
)
return model
return create_model
def create_base_model_bob():
def create_model():
fea_list = ["gender", "age_group", "occupation"]
fea_emb_size = {}
for key in fea_list:
fea_emb_size[key] = [fea_emb_input_size[key], 8]
model = BSTBase(
fea_list=fea_list,
fea_emb_dim=fea_emb_size,
sequence_fea=[],
target_item_fea=None,
seq_len=None,
)
return model
return create_model
def create_fuse_model(mode="ori"):
def create_model():
if mode == 'ori':
model = BSTfuse(dnn_units_size=[77, 64])
else:
model = BSTfuse(dnn_units_size=[50, 64])
return model
return create_model
定义 SL Model#
[7]:
from torch import nn, optim
from torchmetrics import AUROC, Accuracy, Precision
from secretflow.ml.nn.fl.utils import metric_wrapper, optim_wrapper
from secretflow.ml.nn.utils import TorchModel
from secretflow.ml.nn import SLModel
loss_fn = nn.CrossEntropyLoss
optim_fn = optim_wrapper(optim.Adam, lr=1e-2)
mode = 'plus'
base_model_alice = TorchModel(
model_fn=create_base_model_alice(mode),
loss_fn=loss_fn,
optim_fn=optim_fn,
metrics=[
metric_wrapper(Accuracy, task="multiclass", num_classes=2, average='micro'),
metric_wrapper(Precision, task="multiclass", num_classes=2, average='micro'),
metric_wrapper(AUROC, task="binary"),
],
)
base_model_bob = TorchModel(
model_fn=create_base_model_bob(),
loss_fn=loss_fn,
optim_fn=optim_fn,
metrics=[
metric_wrapper(Accuracy, task="multiclass", num_classes=2, average='micro'),
metric_wrapper(Precision, task="multiclass", num_classes=2, average='micro'),
metric_wrapper(AUROC, task="binary"),
],
)
fuse_model = TorchModel(
model_fn=create_fuse_model(mode),
loss_fn=loss_fn,
optim_fn=optim_fn,
metrics=[
metric_wrapper(Accuracy, task="multiclass", num_classes=2, average='micro'),
metric_wrapper(Precision, task="multiclass", num_classes=2, average='micro'),
metric_wrapper(AUROC, task="multiclass", num_classes=2),
],
)
base_model_dict = {
alice: base_model_alice,
bob: base_model_bob,
}
sl_model = SLModel(
base_model_dict=base_model_dict,
device_y=alice,
model_fuse=fuse_model,
random_seed=1234,
backend='torch',
)
INFO:root:Create proxy actor <class 'secretflow.ml.nn.sl.backend.torch.strategy.split_nn.PYUSLTorchModel'> with party alice.
INFO:root:Create proxy actor <class 'secretflow.ml.nn.sl.backend.torch.strategy.split_nn.PYUSLTorchModel'> with party bob.
开始训练#
[8]:
from secretflow.data.vertical import read_csv
vdf = read_csv(
{
alice: gen_data_path + '/train_data_alice.csv',
bob: gen_data_path + '/train_data_bob.csv',
},
delimiter='|',
)
label = vdf["label"]
data = vdf.drop(columns=["label"])
epoch = 1
history = sl_model.fit(
data,
label,
validation_data=(data, label),
epochs=epoch,
batch_size=batch_size,
shuffle=False,
random_seed=1234,
dataset_builder=dataset_buidler_dict,
)
print('history: ', history)
INFO:root:SL Train Params: {'x': VDataFrame(partitions={PYURuntime(alice): <secretflow.data.partition.pandas.partition.PdPartition object at 0x7f7529c6d250>, PYURuntime(bob): <secretflow.data.partition.pandas.partition.PdPartition object at 0x7f75274a7760>}, aligned=True), 'y': VDataFrame(partitions={PYURuntime(alice): <secretflow.data.partition.pandas.partition.PdPartition object at 0x7f75274a7580>}, aligned=True), 'batch_size': 128, 'epochs': 1, 'verbose': 1, 'callbacks': None, 'validation_data': (VDataFrame(partitions={PYURuntime(alice): <secretflow.data.partition.pandas.partition.PdPartition object at 0x7f7529c6d250>, PYURuntime(bob): <secretflow.data.partition.pandas.partition.PdPartition object at 0x7f75274a7760>}, aligned=True), VDataFrame(partitions={PYURuntime(alice): <secretflow.data.partition.pandas.partition.PdPartition object at 0x7f75274a7580>}, aligned=True)), 'shuffle': False, 'sample_weight': None, 'validation_freq': 1, 'dp_spent_step_freq': None, 'dataset_builder': {PYURuntime(alice): <function create_dataset_builder_alice.<locals>.dataset_builder at 0x7f7588b27670>, PYURuntime(bob): <function create_dataset_builder_bob.<locals>.dataset_builder at 0x7f7588b27700>}, 'audit_log_params': {}, 'random_seed': 1234, 'audit_log_dir': None, 'self': <secretflow.ml.nn.sl.sl_model.SLModel object at 0x7f7529c6db80>}
100%|██████████| 1664/1664 [04:01<00:00, 6.90it/s, epoch: 1/1 - train_loss:0.6442505717277527 train_MulticlassAccuracy:0.6493232250213623 train_MulticlassPrecision:0.6493232250213623 train_MulticlassAUROC:0.6861191391944885 val_val_loss:0.6395253539085388 val_MulticlassAccuracy:0.6840226650238037 val_MulticlassPrecision:0.6840226650238037 val_MulticlassAUROC:0.734423816204071 ]
history: {'train_loss': [array(0.6442506, dtype=float32)], 'train_MulticlassAccuracy': [tensor(0.6493)], 'train_MulticlassPrecision': [tensor(0.6493)], 'train_MulticlassAUROC': [tensor(0.6861)], 'val_val_loss': [array(0.63952535, dtype=float32)], 'val_MulticlassAccuracy': [tensor(0.6840)], 'val_MulticlassPrecision': [tensor(0.6840)], 'val_MulticlassAUROC': [tensor(0.7344)]}
总结#
本文通过 movieLens 数据集上的推荐任务来演示了如何通过隐语来训练拆分 BST 模型，您需要 1. 下载并处理数据集； 2. 构造 dataset_builder 处理数据；3. 定义模型结构，调用 BSTBase， BSTPlusBase 和 BSTFuse 定义行模结构； 4. 使用 SLModel 进行训练，预测，评估即可。
您可以在自己的数据集上进行尝试，如有任何问题，可以在 github 上进行讨论。
